Degree of match inspection
9
Continued from the previous page: When the GRAY-IMG-PROC (gray scale processing mode) is selected.
[The setting sequence for criteria condition]
- This is the sequence to follow when model 0 (positioning) is set to NO-SEARCH (do not
search) and model 1 (object to be measured) is set to NO
- This is the sequence to follow when model 0 (positioning) is set to SEARCH (search) and
model 1 (object to be measured) is set to NO
· This is the sequence to follow when model 0 (positioning) is set to SEARCH (search) and
model 1 (object to be measured) is set to YES (NO-SEARCH) (do not search)
- This is the sequence to follow when model 0 (positioning) is set to SEARCH (search) and
model 1 (object to be measured) is set to YES (SEARCH) (do not search)
[Information about the recording of a reference image]
In order to record a reference image it is necessary to use the freeze frame.
The specifications for the windows are as follows.
- In the case of a rectangular window
· In the case of a horizontal line
- In the case of a vertical line
When using either a horizontal or a vertical line, please bear the following in mind.
The length of the reference image must be less than that of the search area.
Continued on the following page
1MEAS WINDOW(MDL0)
(measurement window)
4DTECT COORD(MDL0)
(detection coordinates)
2
REF IMAGE
(MODEL0)
(reference image)
w
UPPER MENU
q
DETECT ACCURANCY
(accuracy of detection)
1MEAS WINDOW(MDL0)
(measurement window)
3
SEARCH AREA (MDL0)
2
REF IMAGE
(MODEL0)
(reference image)
4DTECT COORD(MDL0)
(detection coordinates)
5CONTR. PIXEL(MDL0)
(pixel contraction)
q
DETECT ACCURANCY
(accuracy of detection)
w
UPPER MENU
1
MEAS WINDOW
(MDL0)
(measurement window)
3
SEARCH AREA (MDL0)
2
REF IMAGE(MODEL0)
(reference image)
4DTECT COORD(MDL0)
(detection coordinates)
5
CONTR. PIXEL(MDL0)
(pixel contraction)
6MEAS WINDOW(MDL1)
(measurement window)
7
REF IMAGE
(MODEL1)
(reference images)
9DTECT COORD(MDL1)
(detection coordinates)
qDETECT ACCURANCY
(accuracy of detection)
w
UPPER MENU
1
MEAS WINDOW
(MDL0)
(measurement window)
3
SEARCH AREA (MDL0)
2
REF IMAGE(MODEL0)
(reference image)
4DTECT COORD(MDL0)
(detection coordinates)
5
CONTR. PIXEL(MDL0)
(pixel contraction)
6MEAS WINDOW(MDL1)
(measurement window)
7
REF IMAGE
(MODEL1)
(reference images)
8
SEARCH AREA
(MDL1)
9DTECT COORD(MDL1)
(detection coordinates)
0CONTR. PIXEL(MDL1)
(pixel contraction)
q
DETECT ACCURANCY
(accuracy of detection)
w
UPPER MENU
Reference image
Search area
Line type
Solid line
Dotted line
Movement
In a horizontal direction: units of 4 pixels
In a vertical direction: units of 1 pixel
Length
Units of 4
pixels
Minimum length
8 pixels
Maximum length
512 pixels
Reference image
Search area
Line type
Solid line
Dotted line
Movement
In a horizontal direction: units of 1 pixel
In a vertical direction: units of 4 pixels
Length
Units of 4
pixels
Minimum length
8 pixels
Maximum length
480 pixels
To Next Page
