Distance and angle measurement
9-59
9
Go to page 9·6
Continued on the following page
Go to page 9·61
Select item 6 MEAS.PROG.COND (conditions for measurement programs).
When the GRAV (center of gravity) is selected
[TYPE00-MEAS1]
1MEAS SELECTION
NO CHECK-DEG-OF-MATCH
DST&AGL MES
. (
GRAY&EDGE GRAV)
INSPECT-LEAD MEASR-BIN-AREA
CNT-BIN-OBJ LABEL-BIN-OBJ
POINT MEAS
2COMPARE IMAGES NO YES(CAM1)
3SELECT CAMERA
CAM1 CAM2
4COPY
EXEC←TYPE00
−
MEAS1
−
NO
5INITIALIZATION
EXEC
6MEAS.PROG. COND
(TO NEXT SUB-MENU)
7EVALUATION COND
(TO NEXT SUB-MENU)
8NUMERIC CALC COND
(TO NEXT SUB-MENU)
9OUTPUT CONDITIONS
(TO NEXT SUB-MENU)
0UPPER MENU
This is how the display looks when GRAY&EDGE are selected
Select item 3 START POINT COND (conditions for the starting point)
[MEASURING COND]
(TYPE00-MEAS.1-DST&ANGL.MEAS)
1START POINT NO 00(0~15) REG.NO YES
2START POINT MODE
GRAY-SEARCH EDGE-DETECT
3START POINT COND
(TO NEXT SUB-MENU)
4AUX.CONDITIONS (TO NEXT SUB-MENU)
5DISTANCE COND
(TO NEXT SUB-MENU)
6ANGLE CONDITIONS
(TO NEXT SUB-MENU)
7UPPER MENU
If item 1 START POINT NO is set to YES (enable registration), then items 2 to 6 will be displayed.
On the MAIN OPS MENU, move the cursor to SET-SCRN, and press SET key.
-On the [SYSTEM SETUP], move the cursor to item
2
OBJECT TYPE COND and press SET key.
-Select item
0
MEASUREMENT 1, qMEASUREMENT 2 or w MEASUREMENT 3 on the
[OBJECT TYPE COND] (conditions for object types) menu.
This is how the line looks when
the object type is set to 00 and
the selected measurement is 1.
· Set the DST&AGL MES. (measurement of distance and angle) which can be found under item
1 MEAS SELECTION (select measurements) to either GRAY&EDGE (gray scale search and
edge detection) or GRAV. (center of gravity).
· Item 2 COMPARE IMAGES (calculation between images) will be displayed unless NO is
selected in item 8 NUMERIC CALC COND(camera selection) which is in the [OBJECT TYPE
COND] menu.
Select the GRAY-SEARCH
(gray scale search) for starting point mode
Select the EDGE DETECT
(edge detection) for starting point mode
Measurement conditions
1START POINT NO
2START POINT MODE
(starting point mode)
3START POINT COND
(start point condition)
4AUX.CONDITIONS (auxiliary condition)
5DISTANCE COND (distance condition)
6
ANGLE CONDITIONS
(angular condition)
7UPPER MENU
Setting details
Set the starting point number to any number from 0 to 15 and
then set REG.
(registration) to YES, to save your selection.
Select either GRAY-SEARCH (gray scale search) or EDGE
DETECT (edge detection) as the starting point mode.
These are set in the next menu.
This will return you to the [TYPE00-MEAS1 to 3] menu.
[2] Setting details
An explanation of item 6 MEAS.PROG.COND (conditions for measurement programs) from the
[TYPE00-MEAS1 to 3] menu.
To Next Page
