Distance and angle measurement
9-61
9
1DETECT MODE
CHANGE DRK→BRT BRT→DRK CNTR(BRT DRK)
2DETECT DIRECTION HORI (→ ←) VERT (↓ ↑)
3DETECT AREA MOVE UP.L(224,208) LO.R(287,271)
4THRESHOLD VALUE GRYS.050(0〜255) EDGE.W (1~8)
FLAT.W04(1~16)
5PROC. PROJECTION NO YES
qUPPER MENU
Go to page 9·64
Return to the [MEASURING COND] (measurement conditions) menu and
select item 4 AUX.CONDITIONS (auxiliary condition).
Continued from page 9·59: When the EDGE-DETECT (edge detection) starting point mode is selected as
the START POINT COND (starting point conditions).
· You can switch between displaying all the headings together and displaying each one separately
using the ESC key.
· For more information about the setting for edge detection see page 9·11, “Edge detection”, in
shared settings.
[Setting sequence of the starting point conditions of edge detection]
[Information about setting the starting point conditions of edge detection]
In order to record a reference image it is necessary to freeze the frame.
· Specifications for the area of detection.
1
DETECT
MODE
3
DETECT
AREA
2DETECT DIRECTION
4
THRESHOLD VALUE
5
PROC.PRJECTION qUPPER MENU
Menu
1DETECT MODE
(detection mode)
2DETECT DIRECTION
(detection direction)
3DETECT AREA
(area of detection)
4
THRESHOLD VALUE
(threshold values)
5
PROC. PROJECTION
(artifact processing)
qUPPER MENU
Setting details
Select the detection mode.
(Change point or ; Dark to light ; , Light to dark ; ,
Center (light or dark center))
Select the detection direction.
Draw a dotted-line rectangle around the search area.
· In order to enhance detection performance, make dimension Y as short
as possible.
Set the width of the edge (1 to 8) and the flat (1 to 16) as well as the
difference in the light level (0 to 255).
Select whether to employ artifact processing or not.
-For more information about artifact processing see page 9·12, “Artifact
processing” using shared settings.
This will return you to the [MEASURING COND] menu.
Line type
Dotted line
Movement
Units of 1 pixel
Size
Units of 1 pixel
Minimum
0×0 pixels
Maximum
512×480 pixels
