Distance and angle measurement
9-68
9
[D]
00D Y0
+00000350.0~ +00000355.0 +00000352.0 OK
Continued on the following page
Continued from the previous page: GRAY&EDGE, GRAV.
Return to the [TYPE00-MEAS1 to 3] and select item 9 OUTPUT CONDITIONS (output condition)
[NUMERIC CALC] (TYPE00-MEAS.1-DST&ANGL MEAS)
1CALC.RESULT
N00(0~15)
2OBJECT TYPE NO MATCH[M] CORD[X Y] AUX[HX HY]
DIST[D] ANGL[B] NUM-CALC[NC] CNST[C]
3FORMULA REG.00(0~15) N00(0~15)
+ - ∗/ ←→ DEL. END
4 UPPER&LOWER LIMIT + 00000000.0~ +00000000.0
5OUTPUT NO Y0(0~7) C000(0~107)
6RUN A TEST (SET KEY)
7UPPER MENU
N00
N01
N02
N03
- The number of formulas which can be set are dictated by the selections made in items 2 and 3 as follows.
The numbers ranging from 00 to 15 in front of the characters are registration numbers.
- For more information on numerical calculations see section 9-2 [4] Numerical calculations .
Note: You must run a test using item 6 RUN A TEST before making any calculations.
Numerical calculation
1CALC.RESULT
(calculation result)
2OBJECT TYPE (type)







3FORMULA


4UPPER&LOWER LIMIT
(upper and lower limits)
5OUTPUT
6RUN A TEST
(make a test run)
7UPPER MENU
Setting details
Set the recording and display the results from arithmetical operation for
specified output data at any value from 00 to 15.
Select the type of data being calculated.
A number of formula settings are used.
The first line will change according to the selection made in item 2.
Note: Please use a smaller number for the number of formulas at N (00 to 15)
than that used for 1 CALC. RESULT N (00 to 15).
Set the upper and lower limits for decisions.
Set the output conditions for the results of calculations.
Pressing the SET key will record the setting details as well as run a test.
Returns you to the [TYPE00-MEAS1 to 3] menu.
2OBJECT TYPE
Degree of match [M]
Coordinates [X][Y]
Auxiliary [HX/HY]
Distance [D]
Angle [B]
Numerical calculation [NC]
Constant [C]
Number of formulas
00M to 15M
00X to 15X/00Y to 15Y
00HX to 15Hx/00HY to 15HY
00D to 15D
00B to 15B
ABS/󰵫/TAN/ATAN (00 to 15)
-99999999.9 to +99999999.9
Selection of 2
The degree of match with the reference
image [M] coordinates [XY], auxiliary
[HX, HY], distance [D] and angle [B].
Numerical calculations [NC]
Constant [C]
The first line of the display
Record 00 (0 to 15) N00 (0 to 15)
ABS 󰵫 TAN ATAN N0 (0 to 15) (the
second line will not be displayed)
+00000000.0 (the second line will not
be displayed)
