Area measurement by binary conversion
9
Continued on the following page
Select item 6 MEAS.PROG.COND (conditions for measurement programs).
Select item 2 BINARY AREA COND (conditions for binary areas).
[TYPE00-MEAS1]
1MEAS SELECTION
NO CHECK-DEG-OF-MATCH
DST&AGL MES
. (
GRAY&EDGE GRAV)
INSPECT-LEAD MEASR-BIN-AREA
CNT-BIN-OBJ LABEL-BIN-OBJ
POINT MEAS
2COMPARE IMAGES NO YES(CAM1)
3SELECT CAMERA
CAM1 CAM2
4COPY
EXEC←TYPE00
−
MEAS1
−
NO
5INITIALIZATION
EXEC
6MEAS.PROG. COND
(TO NEXT SUB-MENU)
7EVALUATION COND
(TO NEXT SUB-MENU)
8NUMERIC CALC COND
(TO NEXT SUB-MENU)
9OUTPUT CONDITIONS
(TO NEXT SUB-MENU)
0UPPER MENU
[MEASURING COND]
(TYPE00-MEAS.1-MEAS-BIN-AREA)
1REGST NO.
00(0~15) REG.NO YES
2BINARY AREA COND
(TO NEXT SUB-MENU)
3UPPER MENU
- In item 1, select MEASR-BIN-AREA (measure the area of binary images).
- Item 2 will be displayed unless NO is selected in item 8 SELECT CAMERA
IMG (camera selection) which is in the [OBJECT TYPE COND] menu.
-On the [SYSTEM SETUP menu] move the cursor to 2OBJECT TYPE COND (conditions of
object type and press the SET key.
-Go to item 0 MEASUREMENT 1, item q MEASUREMENT 2 or, item
w MEASUREMENT 3 on the [OBJECT TYPE COND] menu and press the SET key.
This is how the line looks
when the object type is set
to 00 and the selected
measurement is 1.
- If YES is specified in item 1 REGST NO. (registration number), then item 2 will be
displayed.
Measurement conditions
1REGST NO.
(registration number)
2BINARY AREA COND
(conditions for binary areas)
3UPPER MENU
Setting details
Set this to any number from 0 to 15 and select NO or
YES to store it.
The condition for binary areas are set on the next menu.
This will return you to the [TYPE00-MEAS1 to 3] menu.
[2] Setting details
An explanation of item 6 MEAS.PROG.COND (conditions for measurement programs) in the
[TYPE00-MEAS1 to 3] menu.
