9-86
Area measurement by binary conversion
9
These displays can be set using
the up and down keys. (The
choices are NO, Y0 to 7, C000
to C127)
Continued from the previous page
Continued on the following page
Return to the [TYPE00-MEAS1 to 3] menu and select item
8NUMERIC CALC COND (numerical calculation conditions).
[EVALUATIONCOND]
(TYPE00-MEAS.1-MEAS-BIN-AREA)
1REGST NO. 00(0~15)
[
TEST RESULT]
[OUT]
2AREA 000000~245760
002000 OK NO
3MAKE A TEST RUN
(SET KEY)
4UPPER MENU
Select item 7 EVALUATION COND (evaluation condition) on the [TYPE00-MEAS 1 to 3] menu.
Items 2 and 3 will be displayed if the REGST NO. (registration number) is set to YES on the
[MEASURING COND] menu.
· Check your selection by testing the upper and lower limits for evaluations that you have set.
This can be done using item 3 MAKE A TEST RUN.
· For more information about evaluation conditions, see section 9-2 [3] Evaluation condition.
Evaluation conditions
1REGST NO.
(registration number)
2AREA
3MAKEATEST RUN
4PRIOR MENU
Setting details
Select any number from 0 to 15.
Set the range for the area that will produce an OK evaluation.
Pressing the SET key will test the evaluation condition, display
the test results.
This will return you to the [TYPE00-MEAS1 to 3] menu.
