9-87
Area measurement by binary conversion
9
Continued from the previous page
Continued on the following page
Return to the [TYPE00-MEAS1 to 3] menu and select item 9 OUTPUT CONDITIONS.
[NUMERIC CALC] (TYPE00-MEAS.1-MEAS-BIN-AREA)
1CALC.RESULT N00(0~15)
2OBJECT TYPE NO T-AREA[A] NUM-CALC[NC] CNST[C]
3FORMULA REG.00(0~15) N00(0~15)
+ - ∗/
←→ DEL. END
4UPPER&LOWER LIMIT +
00000000.0~ +00000000.0
5OUTPUT NO Y0(0~7) C000(0~107)
6RUN A TEST (SET KEY)
7UPPER MENU
N00
N01
N02
N03
[A]
00A Y0
+00009000.0~+00010000.0 +00009500.0 OK
The numbers ranging from 00 to 15 in front of the characters are registration numbers.
· For more information on numerical calculations see section 9-2 [4] Numerical calculations.
Note: You must run a test using item 6 RUN A TEST, before making any calculations.
· The number of formulas which can be set are dictated by the selections made in items 2 and 3
as follows.
Numerical calculation
1CALC.RESULT
(calculation result)
2OBJECT TYPE
3FORMULA
4UPPER&LOWER LIMIT
5OUTPUT
6RUN A TEST
(make a test run)
7UPPER MENU
Setting details
See the recording and display the results from arithmetical operation for
specified output data at any value from 00 to 15.
Select the type of data being calculated.
A number of formula settings are used.
The first line will change according to the selection made in item 2.
Note: Please use a smaller number for the number of formulas at N (00 to 15)
than that used for 1 CALC. RESULT N (00 to 15).
Set the upper and lower limits for decisions.
Set the evaluation output for the results of the calculations.
Pressing the SET key will record the settings details as well as run a test.
Returns you to the [TYPE00-MEAS1 to 3] menu.
2KIND (type)
Total area [A]
Numerical calculation [NC]
Constant [C]
Number of formulas
00A to 15A
ABS//TAN/ATAN (00 to 15)
-99999999.9 to +99999999.9
Selection of 2
Total area A
Numerical calculations [NC]
Constant [C]
The first line of the display
Record 00 (0 to 15) N00 (0 to 15)
ABS TAN ATAN N0 (0 to 15) (the
second line will not be displayed)
+00000000.0 (the second line will not
be displayed)
To Next Page
