Shimadzu LC-40D XR CL User Manual

4
After tightening the drain valve ASSY,
attach the knob with the screw (B)
using a phillips screwdriver so that it
is vertical, and then attach the cap (C).
4.13 Replacing the Air Filter (Right Panel)
This section explains about replacement on the air filter of the right panel.
Necessary parts
Part Name
Part Type Part No.
Air Filter Element, Non Woven, for Right
Panel
Consumable part 228-53924-06
1
Open the right panel.
2
Remove the right panel cover.
While lightly pressing the cylinder-shaped
projection (a) inside the right panel cover,
slide the cover to the front.
120
LC-40D X3 CL LC-40D XR CL
4 Maintenance
