Shimadzu LC-40D XR CL User Manual

5.2.2 Replacement Parts
No. Part Name Part No. Remarks
9 PUMP HEAD 228-55230-45
10 HEAD HOLDER,2030 228-38022-01
11 Suction Filter ASSY 228-45708-91
12 PEEK Bush Fitting 3 228-39084 For suction filter
13 FERRULE,3.0F-T 228-12493 For suction filter
14 FEP TUBE 3.0 (O.D.)×1.5(I.D.) 670-10321-05 For suction filter
15 INLET BLOCK PEEK 228-47518 Pump inlet
16 DRAIN VALVE ASSY,TP 228-51229-93
17 THRUST 228-34469
18 SUS PIPE L
228-70472-01
For the left pump head of
LC-40D X3 CL
228-70026-01
For the left pump head of
LC-40D XR CL
19 SUS PIPE R
228-70472-02
For the right pump head of
LC-40D X3 CL
228-70026-02
For the right pump head of
LC-40D XR CL
20 TUBE HOLDER 228-70044
21 DRAIN TUBE ASSY 228-25495-93
22 ETFE TUBE 1.6(O.D.)X0.8(I.D.) 228-18495-01
For use between the inlet block
and the check valve
23 MALE NUT 1.6 PEEK 228-35403
For plumbing between the inlet
block and the check valve
132
LC-40D X3 CL LC-40D XR CL
5 Technical Information
