Shimadzu LC-40D XR CL User Manual

5.2.1 Consumable Parts
No. Part Name Part No. Remarks
1
PLUNGER SEAL 228-52711-93
Seal for pump head, with
backup ring
Plunger Seal GFP 228-52711-94 Optional parts
2 Line Filter ASSY, SUS
228-57501-92 LC-40D X3 CL
228-35871-96 LC-40D XR CL
3 Suction filter 228-45707-91 Filter body only (cleaned)
4 Plunger Holder ASSY 228-52069-44 with diaphragm
5
Inlet Check Valve ASSY
228-52964-42 LC-40D X3 CL
228-48249-96 LC-40D XR CL
Inlet Check Valve ASSY, 2 pieces 228-48249-97 LC-40D XR CL
6 Outlet Check Valve ASSY
228-53334-96 LC-40D X3 CL
228-45705-43 LC-40D XR CL
7 DIAPHRAGM 2PCS 228-55272-41
8 AIR FILTER FOR RIGHT PANEL 228-53924-06 Filter only
LC-40D X3 CL LC-40D XR CL
131
5.2 Maintenance Parts
5
