3.1 Settings for the Basic Operation
Before operating this instrument, it is necessary to set the flow rate and the pressure
limit to protect flow line parts such as columns.
See the product specifications before use.
"5.1.1 LC-40D X3 CL Specifications" P.125
"5.1.2 LC-40D XR CL Specifications" P.126
3.1.1 Prior to Key Operation
Touching the central part of the operation panel displays the operation keys that the
user can operate.
3.1.2 Setting Flow Rate
The following is the basic procedure for setting a flow rate [FLOW].
1
Displays the initial screen (the screen
that is displayed when the power is
turned ON).
If the initial screen is not displayed, press
[CE] to display the initial screen.
2
Press [Enter].
The cursor blinks at the input position indicating that the flow rate [FLOW] can be input.
3
Input the flow rate with the numeric keypad and press [Enter].
The flow rate [FLOW] is set and the display returns to the initial screen.
To cancel the input value, press [CE].
3.1.3 Setting Compressibility
1
Press [→] twice on the initial screen.
The FUNCTION setting group is displayed.
3
Operation
16
LC-40D X3 CL LC-40D XR CL
