No. Key Name Function
10 [ - ] Minus Key No use
Regarding the acceptable part of the arrow keys on the touch panel.
When operating the arrow keys, it
responds by touching the part including
the upper and lower range of each key
indication on the operation panel.
No. Description
1 Acceptable part of [↑] key input.
2 Acceptable part of [→] key input.
3 Acceptable part of [↓] key input.
4 Acceptable part of [←] key input.
LC-40D X3 CL LC-40D XR CL
15
2.5 Name and Functions of the Operation Panel
2
