Inspection/Maintenance
Item
Replacement
Periods
Remark Ref.
Replacement of Air Filter
(for Right Panel)
1 year - P.120
Replacement of Air Filter
(for FAN)
1 year Contact your Shimadzu representative. -
Pump ASSY lubrication 3 years Contact your Shimadzu representative. -
Replacement of Fuse 3 years Contact your Shimadzu representative. -
Cleaning of the
Automatic Rinsing Kit
1 year - P.123
Replacement of Pump
Head
(2 years)
Pumping mobile phase mixtures
containing acids such as trifluoroacetic
acid or formic acid can cause leakage
due to internal damage in the pump
head. In such cases, replace the pump
head every two years, as a general
guideline.
(Pump heads do not need to be
replaced if only mobile phases without
acid are pumped.)
-
Inspection of Leak Sensor 1 year - P.54
n Optional Parts
Inspection/Maintenance Item
Replacement
Periods
Remark Ref.
Replacing the Air Filter of
Low Pressure Gradient Kit
1 year
Contact your Shimadzu
representative.
-
4.1.3 Check after Inspection and Maintenance
•
After inspection and maintenance, check any leakage during pumping.
• Return the right panel cover, filter holder and tubes after completing the work.
When the parts management tool (PARTS MGMT TOOL) is not used, input the
part number when replacing a part not registered in the PARTS MGMT TOOL.
"Inputting a replacement part number《PART REPLACEMENT》" P.51
LC-40D X3 CL LC-40D XR CL
83
4.1 Periodic Inspection and Maintenance
4
