2.4 Right Side and Bottom
No. Name Description
1 Mixer Mounting Holes Used to install mixer and column holder.
2 Shipping Screws (Red)
To prevent damage during transportation. LC-40D X3
CL has three screws, and LC-40D XR CL has two screws.
Remove before installation.
3 Leakage Drain Outlet Connect the provided drain tubing.
10
LC-40D X3 CL LC-40D XR CL
