Set Value Setting Method
1 Auto-Diagnostics is on.
"Displays of Condition《CONDITION》" P.25
3.7 Creating Time Program
• The function of the time program is not available when controlled by the
system controller. Configure from the workstation. See " system guide 2.2
Editing Methods"
• Refer to the following procedure when using this function in local mode.
The instrument can run a time program with a flow rate and other parameters. A created
time program is saved in a file. Check for file numbers in use before creating a time
program.
See "Specifying the file number《FILE NUMBER》" P.46 of the auxiliary function to view
or specify file numbers.
3.7.1 Time Program Command List
The commands for the time program are listed below.
Com-
mand
Description Setting Range Remark Ref.
FLOW
Sets flow rate (Available
only in constant flow
solvent delivery mode)
0 to
10.0000 mL/min
Minimum unit:
0.0001 mL/min
P.20
PRESS
Sets delivery pressure.
(Available only in
constant pressure solvent
delivery mode. This can
be set only for
LC-40D XR CL)
10 to 60.0 MPa
10 to 612 kgf/cm
2
10 to 600 bar
142 to 8706 psi
Minimum units:
0.1 MPa
1 kgf/cm
2
1 bar
1 psi
P.21
BCONC
Specifies concentration of
mobile phase B
Only active when [PUMP
CONFIG(SYS)] = 4
*1
0 to 100 %
Minimum unit:
0.1 %
*2
CCONC
Specifies concentration of
mobile phase C
Only active when [PUMP
CONFIG(SYS)] = 4
*1
0 to100 %
*2
Minimum unit:
0.1 %
DCONC
Specifies concentration of
mobile phase D
Only active when [PUMP
CONFIG(SYS)] = 4
*1
0 to100 %
*2
Minimum unit:
0.1 %
LC-40D X3 CL LC-40D XR CL
69
3.7 Creating Time Program
3
