n Setting the time to replace the plunger seal《PLUNGER SEAL》
This allows the user to set the time to
replace the plunger seal (unit: L).
"Displaying the delivery amount of the left plunger seal《L SEAL USED》" P.49
"Displaying the delivery amount of the right plunger seal《R SEAL USED》" P.49
n Selecting how to set the maximum pressure《P.MAX OVERRIDE》 (LC-40D XR CL only)
This allows the user to set the maximum
pressure with keys on the pump even if
[OPERATION MODE] is set to "1" and the
instrument is controlled with the system
controller.
If [OPERATION MODE] is set to "0", the set value will be "0".
"Setting the operation mode《OPERATION MODE》" P.61
Set Value Setting Method
0 To set the value with the system controller.
1 To set the value on the pump.
n Selecting the flow path switching valve《SV SELECT》
Not used in CL model.
This allows the user to select the valve to
use when [OPERATION MODE] is set to "1"
(compatible mode) and the instrument is
controlled with the system controller.
n Turning on/off Auto-Diagnostics《AUTO DIAGNOSTICS》
This allows the user to turn on/off
Auto-Diagnostics.
Set Value Setting Method
0 Auto-Diagnostics is off.
68
LC-40D X3 CL LC-40D XR CL
3 Operation
