n Low Pressure Gradient Kit
Item Specification
Flow Line Switching
Method
Flow Line Switching with the five-way solenoid valve
Number of Flow Lines 1 (with four built-in two way solenoid valve)
Solenoid Valve Operating
Pressure
0 kPa to 50 kPa
Materials for Parts
Exposed to Liquid
PTFE, PEEK, fluororubber
Operating Temperature
4 °C to 35 °C
Available Flow Rate 0.0001 mL/min to 10 mL/min
Available pH 1 to 14
LC-40D X3 CL LC-40D XR CL
129
5.1 Specifications
