[Disconnected] is displayed when a
degassing unit is not connected.
n Displaying the status of connection with PC/WS《PC/WS》
The screen displays the status of
connection with a PC/WS.
[Connected] is displayed when the
instrument is connected with a PC/WS.
This screen is displayed only when the
CBM-40 CL is connected.
[Disconnected] is displayed when the instrument is not connected with a PC/WS.
LC-40D X3 CL LC-40D XR CL
27
