n Setting the maximum pressure during purging《PURGE P.MAX》
Set the maximum pressure during auto
purging.
For a purging operation started by the
[PURGE] key of the instrument, the
maximum pressure limit function works at
2.0 MPa and displays the error shown in
the figure as well as stopping delivery.
Setting Range Setting Step
1.0 to 10.0 MPa 0.1 MPa
10 to 102 kgf/cm
2
1 kgf/cm
2
10 to 100 bar 1 bar
142 to 1451 psi 1 psi
1 kgf/cm
2
= 0.098 MPa = 0.98 bar = 14.2 psi
n Setting the delivery amount of the rinsing pump《RINSING OPERATE》
Set the delivery amount of the optional
rinsing pump.
During delivery or purging operation, if
the setting is "standard", the rinsing pump
starts with 6-second delivery and then
delivers rinsing solution for 2 seconds at intervals of 1 minute. The other settings double
or triple the 2-second delivery time.
The user can set the delivery amount to one of the four levels below.
Selecting "0" disables the rinsing pump.
Based on the delivery amount per hour in the following table, prepare necessary the
amount of the rinse solution for the analysis time.
•
The delivery amount in the table is approximate for rinsing.
• Select "0" when not using the rinsing pump.
• The approximate delivery amount necessary for replacing the rinse solution in the rinsing
flow path is approximately 10 mL.
• To replace the rinse solution in the rinsing flow path, select "4" and operate the pump
approximately 3 minutes.
36
LC-40D X3 CL LC-40D XR CL
3 Operation
