Do not change the factory default value.
Set Value Port
0 The port does not pass through a flow path of FCV-11AL/FCV-11ALS
1 Not used in CL model.
2 Not used in CL model.
3 Not used in CL model.
n Setting the unit of the displayed pressure《PRESSURE UNIT》
Set the unit of the displayed pressure.
Set
Value
Unit of Displayed Value
0 MPa
1
kgf/cm
2
2 bar
3 psi
1 kgf/cm
2
= 0.098 MPa = 0.98 bar = 14.2 psi
42
LC-40D X3 CL LC-40D XR CL
3 Operation
