SICK Flexi Soft User Manual

Table 86: MS LED on the FX3-XTDI I/O module
MS LED Meaning Notes
o
Supply voltage out of range Switch on the voltage supply of the Flexi Soft sys‐
t
em and check at the A1 and A2 terminals of the
main module.
Ö R
ed/
green (1Hz)
With firmware V1.xx.0: invalid
conf
iguration
With firmware ≥V2.00.0:
remediable external error
Check cabling of the flashing inputs.
If all output LEDs are flashing, check the supply
voltage of terminals A1 and A2 on this module.
Ö Gr
een
(1Hz)
System in Stop The application can be started from within the
conf
iguration software.
O Gr
een
System in Run
Ö R
ed
(1Hz)
With firmware V1.xx.0: reme‐
diable e
xternal error
Check cabling of the flashing inputs
With firmware ≥ V2.00.0:
invalid configuration
Ö R
ed
(2Hz)
Serious error in the system,
pr
esumably in this module.
The application was stopped.
Switch thepower supply off and then on again.
If the problem still has not been remedied after
multiple repetitions, replace this module.
Use the configuration software diagnostic func‐
tion.
O R
ed
Serious error in the system,
pr
esumably in a different
module. The application was
stopped.
Switch thepower supply off and then on again.
If the problem still has not been remedied after
multiple repetitions, replace the module showing
Ö red (2Hz). If applicable, also use the diag‐
nostic function in the configuration software to
isolate the affected module.
Table 87: Input LEDs on the FX3-XTDI I/O module
Input LEDs (I1 … I8) Meaning
o
Input is deactivated.
O Gr
een
Input is active.
Ö Gr
een (1Hz) synchronized with the red
MS LED
Input is deactivated and there is a remediable
er
ror.
Ö Gr
een (1Hz) alternating with the red MS
LED
Input is active and there is a remediable error.
NOTE
T
he LEDs indicate the state and are updated approx. every 64 ms.
8.4 Status messages for the FX3-XTDS I/O module
For information on the positions of the LEDs on the FX3-XTDS I/O module, see
f
igure 33, page 58.
OPERATION 8
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
109
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
