Page #141 background imageLoading...
Page #141 background image
CPU0, CPU1, CPU2, CPU3
Weight 111g (±5%)
FX3-
CPU1/2: 119g (±5%)
FX3-CPU3: 133g (±5%)
Ambient data
T
able 124: Ambient data CPUx
CPU0, CPU1, CPU2, CPU3
Enclosure rating (IEC60529) IP20
Ambient operating temperature
(UL/CSA: surrounding air tempera‐
ture)
-25 ... +55°C
Storage temperature -25 ... +70°C
Air humidity ≤95%, non-condensing
Operating altitude Max. 2,000m above sea level (80kPa)
Vibration resistance 5–150Hz/1G (EN60068-2-6)
10–500Hz/3G
r
ms
(EN60068-2-64)
Shock resistance, continuous shock 15g, 11ms (EN 60068-2-27)
Shock resistance, single shock 30g, 11ms (EN 60068-2-27)
12.3.2 I/O module XTIO
Safety-related parameters
T
he data apply to an ambient temperature of +40°C.
Table 125: Safety-related parameters XTIO
XTIO
Safety integrity level (IEC61508)
S
afety integrity level (IEC62061)
SIL 3
Category(ISO13849)
1)
For single-channel outputs with
t
est pulses activated on all safety
outputs (Q1 … Q4)
Category 4
2)
For single-channel outputs with
test pulses deactivated on this
or on any other safety output
(Q1 … Q4)
Category 3
2)
3)
For dual-channel outputs with or
w
ithout test pulses deactivated on
this or on any other safety output
(Q1 … Q4)
Category 4
3)
4)
Performance level (ISO13849) PLe
PFH
D
1)
For single-channel outputs 4.8 × 10
–9
For dual-channel outputs 0.9 × 10
–9
PFD
a
vg
1)
For single-channel outputs 4.2 × 10
–4
For dual-channel outputs 5 × 10
–5
TECHNICAL DATA 12
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
141
Subject to change without notice
