SICK Flexi Soft User Manual

Minimum Typical Maximum
Output current
1)
– – 75mA
Load capacity – – 200nF
1)
The total output current is limited. Maximum sum current of all relay modules at Y14 or Y24is 80mA.
Mechanical data
T
able 186: Mechanical data UE410-2RO/UE410-4RO
UE410-2RO/UE410-4RO
Dimensions (W × H × D) 22.5mm × 96.5mm × 120.8mm
Weight UE410-2RO: 160g (±5%)
UE410-4R
O: 186g (±5%)
Ambient data
T
able 187: Ambient data UE410-2RO/UE410-4RO
UE410-2RO/UE410-4RO
Enclosure rating (IEC60529) IP20
Ambient operating temperature
(UL/C
SA: surrounding air tempera‐
ture)
-25°C ... +55°C
Storage temperature -25°C ... +70°C
Air humidity ≤95%, non-condensing
Operating altitude Max. 2,000m above sea level (80kPa)
Vibration resistance 5-150Hz/1G (EN 60068-2-6)
10-500Hz/3G
r
ms
(EN 60068-2-64)
Shock resistance, continuous shock 15g, 11ms (EN 60068-2-27)
Shock resistance, single shock 30g, 11ms (EN 60068-2-27)
12.3.11 Diode module DM8-A4K
General data
T
able 188: General data diode module DM8-A4K
Diode module DM8-A4K
Stripping length 7 mm
Wire cross-section 0.2 … 2.5 mm²
Screw connection AWG 22–14
Protection class (IEC61140) III
Contamination rating 2
Electrical data
T
able 189: Input data for diode module DM8-A4K
Diode module DM8-A4K
Input voltage (max.) 25 V AC/60 V DC
Reverse voltage 1,000 V
Reverse current 5 µA
Forward voltage 0.8 V
Input current per channel (1/2) 400 mA
12 TECHNICAL DATA
170
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
