12.3.9 EBX1, EBX3 and EBX4 encoder/motor feedback connection units
General data
T
able 175: General data EBX1, EBX3 and EBX4
EBX1, EBX3 and EBX4
Protection class (IEC61140) III
Immunity to interference EN 61000-6-2
Emitted interference EN 61000-6-4
Wire cross-section Single-wire or fine-stranded wire: 0.2 … 1.5mm²
St
randed wire with ferrule:
a) With plastic ferrule max. 0.75mm²
b) Without plastic ferrule max. 1.5mm²
AWG to UL/CUL: 24 … 16
Mechanical data
T
able 176: Mechanical data EBX1, EBX3 and EBX4
EBX1, EBX3 and EBX4
Dimensions (W × H × D) 45mm × 142.3mm × 73.1mm
Weight EBX1: 119g
EBX3: 170g
EBX4: 163g
Ambient data
Table 177: Ambient data EBX1, EBX3 and EBX4
EBX1, EBX3 and EBX4
Enclosure rating (IEC60529) IP20
Ambient operating temperature
(UL/C
SA: surrounding air tempera‐
ture)
-25 ... +55°C
Storage temperature -25 ... +70°C
Air humidity ≤95%, non-condensing
Operating altitude Max. 2,000m above sea level (80kPa)
Vibration resistance 5–150Hz/1G (EN60068-2-6)
10–500Hz/3G
r
ms
(EN60068-2-64)
Shock resistance, continuous shock 15g, 11ms (EN 60068-2-27)
Shock resistance, single shock 30g, 11ms (EN 60068-2-27)
Electrical data
T
able 178: EBX1: Voltage supply for encoder ENC1_24V and ENC2_24V (from FX3-MOCx)
Minimum Typical Maximum
Supply voltage 24VDC (16.8 … 24 … 30VDC)
Supply voltage for UL/CSA applica‐
t
ions
+24VDC
Type of supply voltage PELV or SELV
The supply current for the encoder/motor feedback con‐
nection unit must be externally limited to a maximum
of 1 A – either by connecting it to the voltage supply at
the encoder connection of the FX3-MOCx, by the power
supply unit used or by a fuse.
Encoder voltage supply (ENC1_24V, ENC2_24V, ENC_0V)
TECHNICAL DATA 12
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
165
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
