SICK Flexi Soft User Manual

5.2.10 FX3-EBX connecting cables
Important information
NOTICE
T
ighten the screws of the D-Sub male connectors alternately with one turn each until
the torque is reached.
Torque:
•
Torque for Micro-D-Sub male connector of FX3-MOC: 0.2 Nm
•
Torque for the Sub-D male connector of the EBX connection unit: 0.7 Nm
Connecting cable between the FX3-MOC motion control module and an FX3-EBX
enc
oder/motor feedback connection unit
Connection cables with material numbers and dimensions, see table 199, page 183
Table 39: Connecting cable for FX3-MOCx and FX3-EBXx
Micro D-sub male connector of the FX3-MOCx Sub-D male connector of the
EBX c
onnection unit
PIN Designation PIN
1 ENC1_A+ 1
2 ENC1_B+ 6
3 ENC1_C+ 11
4 ENC1_24V 3
5 ENC2_24V 13
6 ENC2_C+ 14
7 ENC2_B+ 9
8 ENC2_A+ 4
9 ENC1_A- 2
10 ENC1_B- 7
11 ENC1_C- 12
12 ENC_0V 8
13 ENC2_C- 15
14 ENC2_B- 10
15 ENC2_A- 5
Connecting cable between two FX3-EBX encoder/motor feedback connection units
C
onnection cables with material numbers and dimensions, see table 200, page 183
Table 40: Connecting cable for FX3-EBX3 and FX3-EBX4
Sub-D male connector of the EBX connection unit Sub-D male connector of the
EBX c
onnection unit
PIN Designation PIN
1 ENC1_A+ 1
2 ENC1_B+ 6
3 ENC1_C+ 11
4 ENC1_24V 3
5 ENC2_24V 13
6 ENC2_A- 2
7 ENC2_B- 7
ELECTRICAL INSTALLATION 5
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
69
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
