SICK Flexi Soft User Manual

Connecting cables
T
able 199: Connecting cable for FX3-MOCx and FX3-EBXx
Part Type code Part number
•
S
hielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
straight
•
1× D-sub, male connec‐
tor, 15-pin, straight
2m – 2067798
10m – 2067799
•
Shielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
1× D-sub, male connec‐
tor, 15-pin, straight
0.5m – 2111541
2m – 2077261
10m – 2077262
Pin assignment, see
table 39, page 69
Table 200: Connecting cable for FX3-EBX3 and FX3-EBX4
Part Type code Part number
•
S
hielded, twisted pair
•
1× D-sub, male connec‐
tor, 9-pin, straight
•
1× D-sub, male connec‐
tor, 15-pin, straight
0.3m – 2078260
2m – 2067800
10m – 2067801
Pin assignment, see table 40, page 69
Table 201: Connecting cable for direct encoder connection
Part Type code Part number
Sine/Cosine encoder, e.g.,
DF
S60SPro
•
Shielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
1× M12, female con‐
nector, 8-pin, straight
1m – 2094403
3m – 2094426
5m – 2094427
10m – 2094428
SSI encoder
•
Shielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
1× M12, female con‐
nector, 8-pin, straight
1m – 2094402
3m – 2094431
5m – 2094432
10m – 2094433
SSI + Sin/Cos encoder,
e.g., AFS/AFM60Spro
•
Shielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
1× M12, female con‐
nector, 12-pin, straight
1m – 2094372
3m – 2094434
5m – 2094435
10m – 2094436
Pin assignment
•
see
table 43, page 72
•
see table 44, page 73
•
see table 45, page 73
ACCESSORIES 14
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
183
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
