SICK Flexi Soft User Manual

10.3 Error displays shown by status LEDs, error messages, and troubleshooting meas‐
ur
es
The most important error codes, possible causes, and possible troubleshooting meas‐
ur
es are listed in this chapter. These error messages can be displayed with the diagnos‐
tics function of the configuration software if you have established a connection to the
Flexi Soft system.
NOTE
•
F
or information about how to perform diagnostics,please refer to the “FlexiSoft
in the FlexiSoftDesigner Configuration Software” or “Flexi Soft in the Safety
Designer Configuration Software” operating instructions.
•
Error displays and troubleshooting for the individual modules are described in
the sections on the corresponding modules (see "Status messages on the FX3-
CPUx main module", page 106 to see "Status messages of the UE410-2RO and
UE410-4RO relay modules", page 113).
TROUBLESHOOTING 10
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
117
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
