SICK Flexi Soft User Manual

STIO
Response time Depending on the logic configuration, for details see:
see
table 97, page 132
1)
In the event of an error (GND line open circuit) and with a load resistance of at least 2.5kΩ, no more than
t
he specified leakage current flows on the output. For lower load resistances, the leakage current may be
greater; however, the output voltage will be <5V in this case. A downstream device, for example a relay
or a FPLC (fail-safe programmable logic controller) must detect this state as Low.
2)
Example of resulting maximum coil induction: 2,960mH @ 0.5A.
Mechanical data
T
able 155: Mechanical data STIO
STIO
Dimensions (W × H × D) 22.5mm × 96.5mm × 120.6mm
Weight 139g (±5%)
Ambient data
T
able 156: Ambient data STIO
STIO
Enclosure rating (IEC60529) IP20
Ambient operating temperature
(UL/C
SA: surrounding air tempera‐
ture)
-25 ... +55°C
Storage temperature -25 ... +70°C
Air humidity ≤95%, non-condensing
Operating altitude Max. 2,000m above sea level (80kPa)
Vibration resistance 5–150Hz/1G (EN60068-2-6)
10–500Hz/3G
r
ms
(EN60068-2-64)
Shock resistance, continuous shock 15g, 11ms (EN 60068-2-27)
Shock resistance, single shock 30g, 11ms (EN 60068-2-27)
12.3.6 Analog input module ANA0
Safety-related parameters
T
he data apply to an ambient temperature of +40°C.
Table 157: Safety-related parameters ANA0
ANA0
Safety integrity level (IEC61508)
Safety integrity level (IEC62061)
SIL 3
Category(ISO13849) Category 4
Performance level (ISO13849) PLe
PFH
D
0.166× 10
–9
PFD
a
vg
2.5× 10
–5
T
M
(mis
sion time, ISO13849) 20 years
ANA0 general data
T
able 158: ANA0 general data
ANA0
Protection class (IEC61140) III
12 TECHNICAL DATA
152
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
