SICK Flexi Soft User Manual

ANA0
Immunity to interference EN 61000-6-2
Emitted interference EN 61000-6-4
Connection type Dual level spring terminals
Wire cross-section Single-wire or fine-stranded wire: 0.2 … 1.5mm²
St
randed wire with ferrule:
a) With plastic ferrule max. 0.75mm²
b) Without plastic ferrule max. 1.5mm²
AWG to UL/CUL: 24 … 16
Power consumption Max. 2W
Power loss
Interfaces
T
able 159: Interfaces ANA0
ANA0
Data interface Internal bus (FLEXBUS+)
Electrical data
T
able 160: Analog inputs (AI) ANA0
ANA0
Number of inputs 2
Type of inputs Electricity
Max. input voltage 30V DC
Max. current 30mA
Current measuring range 4.0 ... 20.0mA
Sampling repetition time 4.0ms
1)
Input area min. 3.5mA
2)
Input area max. 20.5mA
3)
Measuring resistor R
SHUN
T
Between 1+ and 1-
50 W
Between 2+ and 2-
50 W
Measurement accuracy 1% of the scale value (20mA)
Insulation voltage between AI1 and
AI2
0.5kV
Transmission frequency 10.6kHz
Digital resolution 16bit
Value of the lowest bit 0.4μA
1)
Update rate visible at the output (module cycle time); shorter signal pulses at the inputs may not be
de
tected. A maximum of 32 samples per cycle are evaluated.
2)
Threshold below which a sensor fault is assumed. A max. deviation of 1% (full scale value) gives a
tolerance zone of 3.3mA to 3.7mA.
3)
Threshold above which a sensor fault is assumed. A max. deviation of 1% (full scale value) gives a
tolerance zone of 20.3mA to 20.7mA.
TECHNICAL DATA 12
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
153
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
