Table 202: Connecting cable for directly connecting two encoders
Part Type code Part number
•
S
hielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
straight
•
Flying leads
2m – 2067893
•
S
hielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
Flying leads
1.1m – 2098351
2m – 2077263
Pin assignment, see
table 41, page 70
Table 203: Y-connecting cable for directly connecting two encoders
Part Type code Part number
•
S
hielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
2× M12, female con‐
nector, 8-pin, straight
0.21m/0.21m
/0.41m
– 2094381
0.16m/0.14m
/0.14m
– 2116199
0.21m/2.74m
/2.74m
– 2100634
1.9m/0.49m/
0.27m
– 2117540
2.7m/0.69m/
0.19m
– 2117541
•
S
hielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
2× flying leads
0.21m/1.5m/
1.5m
– 2121173
Pin assignment, see
table 42, page 71
14.3 Accessories for the diode module
Table 204: Diode module DM8-A4K
Part Type code Part number
Diode module for connecting several short-cir‐
c
uit-forming safety pressure mats
DM8-A4K 6026142
14.4 Accessories for muting
Table 205: Muting lamp and cable
Part Type code Part number
Muting lamp with mounting kit – 2020743
LED muting lamp with 2m cable – 2019909
LED muting lamp with 10m cable – 2019910
14 ACCESSORIES
184
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
