SICK Flexi Soft User Manual

XTDS
PFH
D
0.4 × 10
–9
PFD
a
vg
3×10
–5
T
M
(mis
sion time, ISO13849) 20 years
General data
T
able 142: General data XTDS
XTDS
Protection class (IEC61140) III
Immunity to interference EN 61000-6-2
Emitted interference EN 61000-6-4
Connection type Dual level spring terminals
Wire cross-section Single-wire or fine-stranded wire: 0.2 … 1.5mm²
Stranded wire with ferrule:
a) With plastic ferrule max. 0.75mm²
b) Without plastic ferrule max. 1.5mm²
AWG to UL/CUL: 24 … 16
Data interface Internal bus (FLEXBUS+)
Power consumption Max. 1.5W
Power loss
Interfaces
T
able 143: Interfaces XTDS
XTDS
Data interface Internal bus (FLEXBUS+)
Electrical data
T
able 144: Power supply unit (A1, A2) for XTDS
XTDS
Supply voltage 24VDC (16.8 … 24 … 30VDC)
Supply voltage for UL/CSA applica‐
t
ions
+24V DC
Type of supply voltage PELV or SELV
T
he supply current for the module must be limited exter‐
nally to max. 4A – either by the power supply unit used,
or by means of a fuse.
Short-circuit protection 4A gG (with trigger characteristics B or C)
Power consumption Max. 60W (30V × 2A), determined by the load on
out
puts Y3 to Y6
Power-up delay Max. 18s
Table 145: Safety inputs (I) XTDS
XTDS
Number of inputs 8
Input voltage High 13 ... 30V DC
1)
Input voltage Low -5 ... +5V DC
Input current High 2.4 ... 3.8mA
Input current Low -2.5 ... +2.1mA
12 TECHNICAL DATA
148
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
