Assembly and installation
FLOWSIC200 · Operating Instructions · 8013271/1CJ9/V2-0/2022-01 · © SICK Engineering GmbH 47
MCU processor board connections
Fig. 28 MCU processor board connections
Supply voltage 24 V DC RS232 Connection for optional I/O module
Connections for relays 1 to 5 Connections for S/R unit Master
Connections for
analog inputs
1 and 2
Connection for
analog output
Connections for
digital inputs
1 to 4
Connection for
optional
Display module
Connection
for LEDs
Connection
for optional
Interface module
USB plug
connector
Connection
for external
power
supply
