2.7.2 Load recording device with maximum load display
The optional feature "Load recording device with maximum load display" is available for
FLOWSIC500 with integrated volume conversion. The feature is optionally activated at the
factory and extends the archive entries of the measuring period archive, daily archive and
monthly archive by additional details, e. g. time stamps of measurement and process vari-
ables, T
min
,T
max
and flowtime.
The archive contents can be shown on the display. A search function is also available, see
→ p. 99, §5.2.16. Querying the measurement data and external time synchronization are
also possible via the RS485 interface.
When the current measuring period elapses, the consumption and process values of this
period are used for updating the daily and monthly extreme values related to the measuring
period.
When the current day is ended, the consumption and process values of this day are used
for updating the daily related monthly extreme values.
If the feature "Load recording device with maximum load display" is activated, the
FLOWSIC500 checks if the measuring period or the daily period is still valid when ending
the measuring period or the daily period. If the period is valid, the consumption of this
period is used for updating the daily and monthly extreme values.
A period entry is marked as invalid when the following events occur:
● when there is a device malfunction,
● when the target recording duration has not been observed,
● when the time has been set beyond the synchronization limit,
● if the difference between the start and end time stamps does not match the target
period duration.
For the maximum load function, the stored measured values for the currently running and
the previous, i.e. last completed, periods can be shown on the display, see → p. 96,
§5.2.6.10.
The maxima (↑) of the last 24 months in each case are stored in the monthly archive and
can also be viewed on the display.
Explanations on data structure and storage depth are available in Technical
Bulletin “Data Registration”).
You will find the document on the delivered product CD.
