136 FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH
Accessories and spare parts
Subject to change without notice
8.1 Accessories
8.1.1 Gas flow meter accessories
Description Part No.
Mounting set for meter installation 2"/DN50 with flange type ANSI150 (ASME B16.5) 2067402
Mounting set for meter installation 3"/DN80 with flange type ANSI150 (ASME B16.5) 2067403
Mounting set for meter installation 4"/DN100 with flange type ANSI150 (ASME B16.5) 2067404
Mounting set for meter installation 6"/DN150 with flange type ANSI150 (ASME B16.5) 2067405
Mounting set for meter installation 2"/DN50 with flange type PN16 (EN1092-1) 2067406
Mounting set for meter installation 3"/DN80 with flange type PN16 (EN1092-1) 2067407
Mounting set for meter installation 4"/DN100 with flange type PN16 (EN1092-1) 2067408
Mounting set for meter installation 6"/DN150 with flange type PN16 (EN1092-1) 2067409
Mounting set for meter installation 2" | DN50 with flange type PN16 (GOST 12815-80
and GOST 33259—2015); flange face V1 series 1/2
2067411
Mounting set for meter installation 3"| DN80 with flange type PN16 (GOST 12815-80) for
flange face V1 series 1; or with flange type PN16 (GOST 33259—2015) for flange face Ver-
sion B series 2
2067412
Mounting set for meter installation 3"| DN80 with flange type PN16 (GOST 12815-80) for
flange face V1 series 2; or with flange type PN16 (GOST 33259—2015) for flange face Ver-
sion B series 2
2067413
Mounting set for meter installation 4"| DN100 with flange type PN16 (GOST 12815-80
and GOST 33259—2015); flange face V1 series 1/2
2067414
Mounting set for meter installation 6" | DN150 with flange type PN16 (GOST 12815-80
and GOST 33259—2015); flange face V1 series 1/2
2067416
Dummy plug for pressure connection NPT 1/4" 2067398
Dummy plug for temperature connection G1/2" 2067401
M12 plug (A-coded) for data transfer 2067419
M12 connector (B-coded) for power supply 2067420
2 m connection cable for data transfer; -25 °C … +60 °C / -13 °F … +140 °F; with
connector (A-coded) and ferrules
2067422
5 m connection cable for data transfer; -25 °C … +60 °C / -13 °F … +140 °F; with
connector (A-coded) and ferrules
2067423
2 m connection cable for data transfer; -40 °C … +70 °C / -40 °F … +158 °F; with
connector (A-coded) and ferrules
2067630
5 m connection cable for data transfer; -40 °C … +70 °C / -40 °F … +158 °F; with
connector (A-coded) and ferrules
2067631
10 m connection cable for power supply; -25 °C … +60 °C/ -13 °F … +140 °F; with
connector (B-coded) and ferrules
2067424
20 m connection cable for power supply; -25 °C … +60 °C/ -13 °F … +140 °F; with
connector (B-coded) and ferrules
2067425
10 m connection cable for power supply; -40 °C … +70 °C/ -40 °F … +158 °F; with
connector (B-coded) and ferrules
2067632
20 m connection cable for electrical supply; -40 °C … +70 °C/ -40 °F … +158 °F; with
plug (B-coded) and connector sleeves
2067633
Zener Barrier Z715; working voltage 13 V at 10 µA; ATEX II (1) GD [Ex ia Ga] IIC;
DIN rail mounting;
Protection class IP20; Operating temperature -20 to +60 °C |-4 to +140 °F
6079581
Single-channel safety barrier series 9001; operating voltage 12 V DC; ATEX II 3 (1) G Ex nA
[ia Ga] IIC/IIB T4 Gc; CSA Class I, Division 2, Groups A, B, C, D; degree of protection IP20/
40; operating temperature -20 °C … +60 °C
6050603
