Annex
Subject to change without notice
9.2.3 Carbon dioxide concentration (CO
2
) in natural gas
The measuring capability of the FLOWSIC500 is limited by a maximum carbon dioxide con-
centration.
Meter size DN50
Fig. 65 Maximum carbon dioxide concentration DN50
Meter size DN80 / DN100 / DN150
Bild 66 Maximum carbon dioxide concentration DN80 / DN100 / DN150
Pressure [bar(a)]
CO
2
concentration [%]
Pressure [bar(a)]
CO
2
concentration [%]
