Operation
FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH 81
Subject to change without notice
5.2.1 Display in the symbol bar
5.2.2 Battery fill level display
The battery symbol changes as the battery is discharged.
● The last segment of the battery symbol starts to blink when the battery fill level drops
below 10%.
● When the battery is completely empty, the empty battery symbol blinks and the
FLOWSIC500 has switched to the second battery.
Table 24 Symbols
Symbol Significance Description
External power supply Only displayed when the device is configured with external
power supply.
Battery fill level, battery 1 Displayed when the FLOWSIC500 is configured for battery
operation: Status of the first battery pack
Details on the battery fill level → p. 81, §5.2.2.
Battery fill level, battery 2 With external power supply: Backup battery status.
With battery operation: Second battery pack status.
Details on the battery fill level → p. 81, §5.2.2.
Device status: Malfunction The device has an error, the measured value is invalid.
Device status: Warning The device has a warning, the measured value is still valid.
Registered events Events have occurred since the last event summary reset.
Parameter locking switch
closed
Metrologically relevant parameters are protected against
changing; modifications are registered in the Metrology
logbook → p. 31, §2.8.2.
Parameter locking switch
open
Metrologically relevant parameters can be changed; the
modifications are not saved in the Metrology logbook.
Configuration mode Device parameters can be changed.
NOTICE:
In device status “Malfunction” or “Warning”, the respective symbols are shown
blinking on the display.
Table 25 Battery fill level display
Battery fill level > 75%
Battery fill level > 50%
Battery fill level > 25%
Battery fill level > 25%
Battery almost empty but still in use
