Operation
Subject to change without notice
5.2.9.2 Starting and terminating calibration mode
Calibration mode can be started and terminated in the same manner as the configuration
mode (→ p. 98, §5.2.9.2).
In calibration mode, message “CALIBRATION MODE” blinks on the main display with the
meter factor now effective for the calibration (set at the factory).
The FLOWSIC500 outputs test pulses with a maximum possible frequency of 2 kHz at
120% Q
max
.on digital switching output DO_1 (→ p. 34, § 3.4.6.1).
5.2.10 Changing parameters
Numerical values
1 Start the configuration mode (→ p. 97).
2 Select the desired parameter in the menu.
3 Press ENTER to start the edit mode.
The cursor now blinks under the first position of the parameter.
4 Use the arrow buttons to increment or decrement the selected position by 1 until the
correct digit is shown.
5 Confirm with ENTER.
The cursor now blinks under the second position of the parameter.
6 Repeat for all remaining positions of the parameter.
Selection lists
1 Start the configuration mode (→ p. 97).
2 Select the desired parameter in the menu.
3 Press ENTER to start the edit mode.
4 use the arrow buttons to switch to the desired selection.
5 Confirm with ENTER.
5.2.11 Resetting the error volume
1 Switch to the error volume display on the main screen.
2 Press ENTER to start the edit mode.
3 Use the arrow buttons to select OK.
4 Confirm with ENTER.
The error volume is reset.
5.2.12 Resetting the event summary
1 Switch to the “Event Summary” display on the main display.
2 Press ENTER to open a list of the stored events.
3 Press ENTER to start the edit mode.
4 Use the arrow buttons to select OK.
5 Confirm with ENTER.
The event summary is reset.
