SICK FLOWSIC500 User Manual

Maintenance and meter exchange
FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH 127
Subject to change without notice
7.4.11 Loading the parameter backup
1 Connect to device, → p. 71, §4.3.1.
2 Open the “Meter Replacement” tile in the “Service” menu.
3 Set the source for the parameter exchange to “Parameter file”.
4 Select the parameter file stored before exchanging the meter, → p. 116, §7.4.6.
Fig. 55 Parameter file
5 An overview of the old and new values is shown under “Values to replace”. Activate the
“Show only differences” checkbox to show only the differences.
6 Activate Configuration mode.
7 Click “Start Value Exchange” to load the parameter backup.
Fig. 56 Starting the exchange
NOTICE: Parameter protection
▸ Check the position of the parameter locking switch, see → p. 81, §5.2.1.
▸ When open, proceed with step 1.
▸ When closed, the counter values and the configuration of the digital outputs
cannot be written to the meter.
An information message is output when the parameters are being written. If
the further parameters are however to be written, click “OK” to confirm the
information message
