104 FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH
Clearing malfunctions
Subject to change without notice
6.3 Additional messages in the Event logbook
The FLOWSIC500 saves all status messages (→ p. 102, §6.2) as well as further
supplementary messages concerning events and status changes in the Event logbook.
Each message code is supplemented with a (+) or (-) to identify an incoming message = (+)
or an outgoing message = (-).
Table 29 Information messages in the Event logbook
Table 30 Warning messages in the Event logbook
Table 31 Error messages in Event logbook
In the Event logbook, additional data, e.g. status, totalizer levels, measured values and
parameters at the time of certain events are saved.
These events or messages are identified with
*)
. The data can be viewed and saved with
the FLOWgate
TM
operating software (→ p. 78, §4.3.5).
Status message Description/clearance
I-1001 Event logbook has been reset
I-1002 Parameter logbook has been reset.
I-1003 Metrology logbook has been reset.
I-1004 Measuring period archive has been reset.
I-1005 Daily archive has been reset.
I-1006 Monthly archive has been reset.
I-1010 Event overview has been reset.
*)
I-1011 Time has been reset.
*)
I-1012 Totalizers have been reset.
I-1013 Error volume totalizers have been reset.
*)
I-1014 All parameters have been reset or a group of parameters have been reset.
*)
I-1021 Battery (1) has been replaced.
I-1022 Battery (2) has been replaced.
I-1023 Totalizers have been preset.
*)
I-1025 Gas composition logbook reset
I-1026 Gas parameters changed
Status message Description/clearance
W-2011 The number of valid measurements (performance of flow rate measurement) is
significantly lower than normal.
*)
W-2012 Flow rate measurement is performed with reduced precision.
*)
W-2013 Flow rate higher than 120% Q
max
.
W-2021 Entry with invalid CRC in the measuring period archive.
W-2022 Entry with invalid CRC in the daily archive.
W-2023 Entry with invalid CRC in the monthly archive.
Status message Description/clearance
E-3002 Check sum of totalizers is invalid.
E-3003 Check sum of firmware is invalid.
E-3004 Parameter is invalid.
*)
E-3005 Check sum of logbooks/archives is invalid.
*)
E-3015 Hardware error in flow rate measurement.
*)
E-3016 Number of valid measurements (performance of flow rate measurement) is not suffi-
cient.
*)
