SICK FLOWSIC500 User Manual

Annex
FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH 149
Subject to change without notice
9.3.6 AGA8-92DC (AGA-8 Detail)
Parameter Normal range Expanded range Unit
Mole fraction Methane 0.45 - 1.0 0 - 1 mol/mol
Mole fraction N2 0 - 0.5 0 - 1 mol/mol
Mole fraction CO2 0 - 0.3 0 - 1 mol/mol
Mole fraction Ethane 0 - 0.1 0 - 1 mol/mol
Mole fraction Propane 0 - 0.04 0 - 0.12 mol/mol
Mole fraction Water 0 - 0.0005 0 - dew point
[4]
mol/mol
Mole fraction HydrogenSulphide 0 - 0.0002 0 - 1 mol/mol
Mole fraction H2 0 - 0.1 0 - 1 mol/mol
Mole fraction CarbonMonoxide 0 - 0.03 0 - 0.03 mol/mol
Mole fraction Oxygen - 0 - 0.21 mol/mol
Mole fraction i-Butane 0 - 0.01
[1]
[1] The sum of all butane fractions must not exceed the specified limit.
0 - 0.06
[1]
mol/mol
Mole fraction n-Butane 0 - 0.01
[1]
0 - 0.06
[1]
mol/mol
Mole fraction i-Pentane 0 - 0.003
[2]
[2] The sum of all pentane fractions must not exceed the specified limit.
0 - 0.04
[2]
mol/mol
Mole fraction n-Pentane 0 - 0.003
[2]
0 - 0.04
[2]
mol/mol
Mole fraction n-Hexane 0 - 0.002
[3]
[3] The sum of all hydrocarbon fractions ≥ Hexane must not exceed the specified limit.
[4] The algorithm is only valid up to the dew point. Before applying the algorithm,make sure that the gas is completely
in the gas phase (below dew point).
0 - dew point
[3][4]
mol/mol
Mole fraction n-Heptane 0 - 0.002
[3]
0 - dew point
[3][4]
mol/mol
Mole fraction n-Octane 0 - 0.002
[3]
0 - dew point
[3][4]
mol/mol
Mole fraction n-Nonane 0 - 0.002
[3]
0 - dew point
[3][4]
mol/mol
Mole fraction n-Decane 0 - 0.002
[3]
0 - dew point
[3][4]
mol/mol
Mole fraction Helium 0 - 0.002 0 - 0.03 mol/mol
Mole fraction Argon - 0 - 0.01 mol/mol
Pressure 0 - 1379 0 - 1379 bar(a)
Temperature -129 - 204 -129 - 204 °C
