Page #113 background image
113
MSL coded version
FIN
8 007 898/O369/05-04-04 Käyttöohje • MSL cod. © SICK AG • Industrial Safety Systems • Saksa • Kaikki oikeudet pidätetään
6 Tekniset tiedot
Jännitelukemat: DC • Mittausarvojen lähtökohta: laitepistoke
min. tyypill. maks.
Yleiset järjestelmätiedot
Toimintaetäisyys
lähetin/vastaanotin 0,5 m 70 m
MSLZ 01-250 PSK 45 Kulmapeilillä 0 m 7,5 m
MSLZ 01-250 PSZ 01-1501 Kulmapeilillä 0 m 6,1 m
MSLZ 01-240 PSK 45 Kulmapeilillä 0 m 4,5 m
MSLZ 01-240 PSZ 01-1401 Kulmapeilillä 0 m 4,5 m
MSLZ 02-203 PSK 45 Kulmapeilillä 0 m 4,5 m
MSLZ 02-203 PSZ 01-1401 Kulmapeilillä 0 m 4,5 m
MSLZ 02-203 PSZ 02-1011 S 01 Kulmapeilillä 0 m 4,5 m
Valonsäteiden etäisyys 50 mm 500 mm
Resoluutio (tyypitä riippuva) 73 mm
Suojausluokka 1
Kotelointiluokka IP 65
Käyttöjännite U
V
19,2 V 24 V 28,8 V
Ripple
1
) 2,5 V
SS
Jännite verkkokatkoksen aikana (20 ms) 18 V
Tahdistus optinen, ilman erillistä
tahdistusjohtoa
Päällekytkentääika
käyttöjännitteen kytkemisen jälkeen
vastaanottimeen ja lähettimeen 0,8 s
Lähetinyksikkö
Testilähtö U
V
– 1,4 V
Testitulo
tulovastus (HIGH) 2,4 kW (vastaan 0 V)
lähetin passiivinen (testi) 0 V 5 V
lähetin aktiivinen 17,8 V U
V
reaktioaika testiin 90 ms 100 ms
avautumisaika, avautuvat koskettimet 100 ms
Aaltopituus 880 nm
Ottoteho
MSLS 7 W
MSLZ 12 W
Paino (MSLS 03-140) 3,14 kg
241967_MSLcv_FIN_4.p65 10.12.04, 09:36113
