MSL coded version
8 007 898/O369/05-04-04 Operating instruction • MSL cod. © SICK AG • Safety Systems • Germany • All rights reserved
5
1
7
6
4
3
2
8
9
Part numbers
Quick-disconnect plug 2 017 537
Quick-disconnect plug,
angled 2017 755
Cable entry receptacle 6 008 441
1+ 24 V
20 V
3 Test 
4 Test 
5RW
6RW
7 PE
8 n. c.
9 n. c.
1
3
2
4
5
6
7
8
9
10
11
12
Interconnectron (12)
Interconnectron (9)
1+ 24 V
20 V
3 OSSD 1
4 OSSD 2
5 RES
6 EDM
7 OWS
8 PE
9 n. c.
10 n. c.
11 n. c.
12 n. c.
6
Part numbers
Quick-disconnect plug 2 017 536
Cable entry receptacle 6 008 440
