SICK nanoScan3

 nanoScan3 Pro – EtherNet/IP™
Services
•
E
therNet/IP CIP Safety
•
CoLa2 (Configuration and diagnostics using Safety
Designer)
•
Data output
•
DHCP
•
SNMP
•
SNTP (client and server)
Table 34: Electrical data
 nanoScan3 Pro – EtherNet/IP™
Operating data
Protection class III (IEC 61140)
Supply voltage V
S
24VDC (16.8V to 30VDC) (SELV/PELV)
1)
Residual ripple ±5%
2)
Start-up current at 24V ≤1.3A
Current consumption at 24V
Operation Typ. 0.23A
Sleep mode Typ. 0.2A
Power consumption
Operation Typ. 5.5W
Sleep mode Typ. 4.8W
Power-up delay ≤12s
1)
The power supply unit must be able to jumper a brief power failure of 20ms as specified in IEC60204-1.
Suit
able power supply units are available as accessories from SICK.
2)
The voltage level must not fall below the specified minimum voltage.
Table 35: Mechanical data
 nanoScan3 Pro – EtherNet/IP™
Dimensions (incl. system
plug, W × H × D)
106.6mm × 80.2mm × 117.5mm
Weight (including system
plug)
0.67kg
Housingmaterial Aluminum
Housing color RAL 9005 (black) and RAL 1021 (colza yellow)
Optics cover material Polycarbonate
Table 36: Ambient data
 nanoScan3 Pro – EtherNet/IP™
Enclosure rating
1)
IP65 (IEC 60529)
Ambient light immunity ≤40klx
2)
Ambient operating tempera‐
t
ure
–10°C … 50°C
Storage temperature –25°C … 70°C
Air humidity ≤95%, non-condensing
3)
Height above sea level during
oper
ation
≤2,300m
Vibration resistance
4)
TECHNICAL DATA 13
