Description
● Country Code
Select the country in which the device will be operated from the drop-down list.
You do not need to know the data for the specific country, the channel division and output
power are set by the device according to the country you select.
Note
Locale setting
The correct country setting is mandatory for operation complying with the approvals.
Selecting a country different from the country of use can lead to legal prosecution.
● Device Mode
Select the mode of the device. This selection is available only for access points.
The following modes are possible:
– AP - Access point mode
– Client - Client mode
Note
After the mode is changed, a message is displayed. If you confirm the message with "OK",
the device restarts in the changed mode with the factory-set configuration settings.
If the device has restarted, you will need to log on again to be able to continue the
configuration.
The table has the following columns:
● Radio
Shows the available WLAN interfaces.
● Enabled
Status of the WLAN interface. To enable the WLAN interface, select the check box.
Note
Enabling the WLAN interface
The WLAN interfaces are disabled when the device is supplied. The WLAN interfaces are
can be enabled once the country and the antenna settings are configured.
● Radio Mode
Shows the mode of the WLAN interface.
Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
224 Configuration Manual, 11/2019, C79000-G8976-C485-03
