● Frequency Band
Specify the frequency band.
– 2.4 GHz
– 5 GHz
● WLAN mode 2.4 GHz/WLAN mode 5 GHz
Select the required transmission standard for the configured frequency band. The selection
depends on the country setting.
– 802.11g
The transmission standard IEEE 802.11g (2.4 GHz) is set. This transmission standard is
downwards compatible with IEEE 802.11b.
– 802.11n
The transmission standard IEEE 802.11n (2.4 GHz and 5 GHz) is set. This transmission
standard is downwards compatible with IEEE 802.11a and IEEE 802.11g.
– 802.11a
The transmission standard IEEE 802.11a (5 GHz) is set.
– 802.11ac
The transmission standard IEEE 802.11ac (5 GHz) is set.
Note
Data rate
The data rate is adjusted automatically.
Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
Configuration Manual, 11/2019, C79000-G8976-C485-03 225
