Description
Table 1 has the following columns:
● Column 1
Shows that the settings are valid for all ports of table 2.
● Spanning Tree Status
In the drop-down list, select the setting for all ports. If "No Change" is selected, the entries
of the corresponding column in table 2 remain unchanged.
● Copy to Table
If you click the button, the settings are adopted for all ports of table 2.
Table 2 has the following columns:
● Port
Shows the available ports and interfaces.
– Port X
– WLAN X
– VAP X.Y
– WDS X.Y
● Spanning Tree Status
Specify whether the port is integrated in the spanning tree or not.
Note
If you disable the "Spanning Tree Status" option for a port, this may cause the formation of
loops. The topology must be kept in mind.
● Priority
Enter the priority of the port. The priority is only evaluated when the path costs are the same.
The value must be divisible by 16. If the value that cannot be divided by 16, the value is
automatically adapted.
Range of values: 0 - 240.
The default is 128.
● Cost Calc
Enter the path cost calculation. If you enter the value "0" here, the automatically calculated
value is displayed in the "Path Cost" box.
Configuring with Web Based Management
6.7 "Layer 2" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
Configuration Manual, 11/2019, C79000-G8976-C485-03 273
