Siemens Simatic CFU User Manual

Object in HW
Config
Tab
1)
Explanations Supplementary information
Slot 0/X1 Pn R
(parameter for a
port on the Bu‐
sAdapter)
General Name for the PN/IO port on the BusAdapter
(Pn = P1 = Port 1 or Pn = P2 = Port 2)
Addresses Diagnostic address for the PN/IO port on the Bu‐
sAdapter
Identification Higher level designation; location designation;
installation date; supplementary information
Topology Partner port; line data
Recommendation:
Set these parameters in the topology editor.
PROFINET installation > Topolo‐
gy
PROFINET functions > Topology
and STEP 7
Options
● Transmission medium with transmission rate
● Autonegotiation
● Boundaries:
End of sync domain, End of detection of
accessible nodes, End of topology discovery
Slot DIQ
(Freely configu‐
rable channels)
General Name for the freely configurable channels of the
CFU
Section "Configuring freely con‐
figurable channels (parameter
overview - DIQ) (Page 94)"
Addresses Inputs, outputs
You can specify the address range by entering a
start address.
Parameter For example channel type (input/output), diag‐
nostics
Slot FB M
(only for
CFU PA)
General Name of the "PROFIBUS PA Master" interface Section "CFU PA: Assigning pa‐
rameters to the PROFIBUS PA
Master (parameter overview - FB
M) (Page 97)"
Parameters + Di‐
agnosis
General
● Name of the parameter interface of the
PROFIBUS PA Master
Addresses
● Setting diagnostic address
Parameters
● Display DPV0 alarms on CFU PA LEDs
● Comparing TAGs
● Service interface
● Manual field device integration
Status + Notifica‐
tions
General Name of the status interface of the PROFIBUS
PA Master
Addresses Addresses used internally (these must not be
changed)
Slot FB<n>
(only for CFU
PA)
(configuration
places for field
devices on
PROFIBUS
PA
2
)
General Name for the respective field device
in the "Addresses" area:
Diagnostic addresses for the field device
Parameter Assign‐
ment
Are set via SIMATIC PDM.
1)
You can find additional information on the tabs in the STEP 7 online help.
2)
For information only / no modification of the function possible, you can only enter comments.
Commissioning
8.8 Commissioning (offline)
SIMATIC CFU
92 Commissioning Manual, 08/2019, A5E39252870-AD
