10.8 Trace function (SW 4.2 and higher)
10-222
 Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
10.8 Trace function (SW 4.2 and higher)
Note
The trace function can be used only with MMC 102/103 or the start-up tool.
10.8.1 Description
Servo trace function with graphic user interface for checking and monitoring
drive/servo signals and states. You can select measuring signals and set the
measuring parameters with softkeys and dropdown lists. The function is oper-
ated using the mouse or keyboard.
Individual functions of the trace function
S 4 trace buffers with up to 2048 values each
S Selection of SERVO and 611D signals (in position control cycle)
S Trace/trigger signals can be set with the absolute address and value mask-
ing.
S Different trigger conditions to start recording.
Triggering always on trace 1
S Pretriggering and posttriggering possible
S Measuring signal display
S Fixed Y scaling selectable for each trace.
S Marker function selectable for each trace. Expand function in the time axis.
S Selective loading and saving of the measuring parameters and traces.
Function
overview
