11
03.96
11.3 Data backup via MMC 102/103
11-257
 Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
11.3.2 Output of drive data via V.24 on MMC102/103
The following types of drive data are used:
S Boot files (HSA.BOT)
S Boot files (VSA.BOT)
S Drive machine data (*.TEA)
data Directory Name Meaning
Boot file Diagnosis\FDD data VS1.BOT Boot file for 1st axis
Boot file Diagnosis\MSD data HS1.BOT Boot file for 1st spindle
Drive MD FDD DIAGNOSIS\MachDat/FDD *.TEA Drive machine data file for FDD saved
under IBN/MD/Filefunction. A name
must be allocated.
Drive MD MSD DIAGNOSIS\MachDat/MSD *.TEA Drive machine data file for MSD
saved under IBN/MD/Filefunction.
A name must be allocated.
The boot files are stored in the FDD data and MSD data directories.
VS2.BOT
VS1.BOT
FDD data
MSD data (HS1.BOT)
Note
The boot files can only be output as binary files with V.24 setting archive for-
mat. The boot files must have been saved before output (save boot files soft-
key). The boot file data backup (in binary format) can only be loaded back onto
the same software version.
The drive machine data must be saved initially in the Start-up\Machine data\File
function area before they can be output via V.24.
DIAGNOSIS
MachDat/FDD
MachDat/MSD
Drive data
Where are the boot
files stored?
Drive MD
11 Data Backup
