10.8.4 Performing measurement
After parameterization, measurement is started by operating the
softkey Start. How measuring is performed depends on the conditions defined
under measuring parameters/“Trigger” field.
Measurement is terminated after the time set under measuring parameters/input
field “Measuring duration” or is stopped when you operate the softkey Stop.
Interrupted measurement cannot be displayed (softkey display).
Start measurement
End of
measurement
